CASE 770 Backhoe Loader Specification and Features

Price (Excl. Tax)Inquire
CASE 770 Backhoe Loader Specification and Features
CASE Logo
Engine Power
76 HP
Operating Weight
7500 Kg
Call Sales
  • 150-Point Inspection Certified
  • Global Logistics & Shipping Available
  • Clear Title Guarantee

Machine Description

The CASE 770 Backhoe Loader is a powerful and versatile machine built for demanding tasks. Its robust design, featuring a 76 HP turbocharged engine and a 4160 cc displacement, ensures exceptional performance across diverse applications. With a maximum lifting capacity of 3425 kg and a generous 1 cum bucket capacity, this backhoe loader boasts impressive productivity. The 770's impressive dump height of 3550mm and dig depth of 4335mm, combined with its robust hydraulic system (190 Bar), make it ideal for a wide range of excavation and material handling operations. Built to withstand tough conditions, it features a heavy-duty oscillating steering axle and oil-immersed wet disc brakes for superior control and safety. The CASE 770 offers an optimal balance of power, precision, and durability, making it a cost-effective solution for construction, agriculture, and other demanding industries. BS-III compliant.

Tech Specifications

CompliantBS-III
Displacement4160 cc
Air Intake TypeTurbo charged Water Cooled
Gross Power76 HP
Maximum Torque300 NM
Dump Height3550 mm
Dump Angle43 °
Bucket Capacity (Standard)1 Cum
Max Pay Load1760 Kg
Maximum Lifting Capacity3425 Kg
Loader Bucket Capacity1 Cum
Max Reach (Bucket Dumped)2357 mm
Maxd Dig Depth4335 mm
Bucket Rotation204 Degree
Bucket Breakout Force5093 Kgf
Max Lift Capacity1315 Kg
Max Operating Weight7500 Kg
Transport Length5887 mm
Wheelbase2200 mm
Overall Transport Height3887 mm
Pump TypeGear Pump
Pump Flow121 lpm
Engine Oil9.5 Ltr
Rear Axle22 Ltr.
Transmission Oil Capacity16 Ltr.
Fuel Tank122 Ltr
Coolant18 Ltr.
Hydraulic Oil System142 Ltr
RearRigid with planetary drives
FrontHeavy Duty oscillating 20 Deg type Steering axle
TypeHydraulic actuation with independent Hydraulic Circuit
System Pressure190 Bar
Brakes ServiceOil immersed wet disc brakes on rear wheels hydraulically actuated
Hd Tyre Rear Optional14X25 - 20 PR
Standard Tyre Front16.9X28
Standard Tyre Rear16.9X28
Battery12 V,130 Ah
Forward4.8/7.8/16.6/29.7
Reverse5.8/9.3/Not Recommended
BrandCASE
💬
